Aero Engine & Turbomachinery Telemetry

MANNER Aero Engine & Turbomachinery Telemetry is a modular, fully digital telemetry platform for harsh environments, supporting high channel counts, high sampling rates, remote adjustability, and real-time health monitoring with advanced analysis tools.

Downloads

PDF FILE

PDF FILE

Aero Engine & Turbomachinery Telemetry

Engineered for demanding turbomachinery measurement tasks with exchangeable module concepts and flexible coupler configurations (radial/axial). The system provides system setup, acquisition, health monitoring, and real-time analysis tools.

Key Benefits

Temperature resistance up to 170 °C (338 °F)
Up to 256 simultaneous channels
Up to 200 kHz sample rate @ 16-bit resolution
Fully digital transmission
Fully remotely adjustable
Real-time telemetry health monitoring
APEX software interface

Monitoring & Analysis

Trigger values for alerts + recording around alert events
Real-time tools: FFT, Waterfall, Oscilloscope, Bargraph, XY diagram, Order diagram
Telemetry health monitoring & sensor health monitoring (open lines, short circuits)

Configurations

Radial coupler configuration (Flexy system with exchangeable modules)
Axial coupler configuration (Flexy system with exchangeable modules)

Technical Data

Max temperature	Up to 170 °C (338 °F)
Channels	Up to 256 simultaneous
Sample rate	Up to 200 kHz
Resolution	16 bit
Transmission	Fully digital
Adjustment	Fully remotely adjustable
