MANNER OptiMA Telemetry – Plug & Play Kit

MANNER OptiMA Telemetry is an easy-to-use, robust plug & play entry system for torque measurement on rotating shafts. Maintenance-free inductive telemetry enables continuous operation without batteries and supports torque and temperature measurement in harsh environments.

Downloads

PDF FILE

OptiMA Telemetry – Plug & Play Torque Measurement on Rotating Shafts

OptiMA is designed for customers who want a quick start into rotating torque measurement with minimal training effort. The system supports commissioning by the customer and is proven in rough environments (e.g., agriculture).

Key Benefits

Direct measurement of torque, temperature, and vibrations on rotating parts in real operation
Maintenance-free continuous measurement (no batteries)
Large rotor-to-stator distance to prevent collisions (up to 60 mm)
Waterproof IP67 stator unit with integrated sensor signal outputs
Remote control functions: sensitivity, auto-zero offset, sensor check
Optional software recording + optional Wi-Fi / smartphone interface

Technical Data

Rotor-to-stator distance	Up to 60 mm
Supply voltage	9–32 V
Sampling rate	1 kHz (optional 10 kHz)
Analog outputs	±10 V; 4–20 mA; frequency (60 kHz ±30 kHz)
Digital outputs	Ethernet / CAN
Stator temperature range	−25 °C to 85 °C
Stator geometry	144 × 47 × 64 mm
Connector	12-pin Binder plug
System	Inductive high-distance telemetry, maintenance-free
