MANNER Aero Engine & Turbomachinery Telemetry System

MANNER Aero Engine & Turbomachinery Telemetry is a modular, fully digital telemetry platform for high-channel-count measurements in harsh environments. Supports high sampling rates, remote adjustability, and real-time health monitoring with advanced analysis tools.

Downloads

Aero Engine & Turbomachinery Telemetry

Engineered for demanding turbomachinery measurement tasks with high channel counts and high sampling rates. The system provides flexible coupler configurations (radial/axial) and exchangeable modules, with robust monitoring and analysis capabilities.

Key Benefits

Temperature resistance up to 170 °C (338 °F)
Up to 256 simultaneous channels
Up to 200 kHz sample rate @ 16-bit resolution
Fully digital transmission
Fully remotely adjustable
Real-time telemetry health monitoring
APEX software interface

System Setup / Monitoring / Analysis

System setup and acquisition
Health monitoring for telemetry & sensors (open lines, short circuits)
Trigger-based alerts and recording around alert events
Real-time tools: FFT, Waterfall, Oscilloscope, Bargraph, XY, Order

Typical Configurations

Radial coupler configuration (Flexy system with exchangeable modules)
Axial coupler configuration (Flexy system with exchangeable modules)
End-of-shaft solutions in aluminium or titanium versions
Example channel setups (e.g., strain gage + temperature), available up to 64 channels per end-of-shaft solution

Technical Data

Max temperature	Up to 170 °C (338 °F)
Channels	Up to 256 simultaneous
Sample rate	Up to 200 kHz
Resolution	16 bit
Transmission	Fully digital
Adjustment	Fully remotely adjustable
